The First SQL Engine for Apple Silicon GPUs Is Now a DuckDB Community Extension

In May 2026 I shipped gpudb v0.1 — the first SQL execution engine targeting Apple Silicon GPUs, built as a DuckDB extension with a CUDA backend on Linux. Three releases later, the project crossed two lines at once. v0.3.0's streaming-aggregate rewrite reached parity with native DuckDB on end-to-end TPC-H queries — the worst cell improved roughly 100×, from 11.05 s to 0.109 s. And gpudb became an official DuckDB Community Extension: INSTALL gpudb FROM community now works in any DuckDB ≥ 1.5.5, signed, no flags. This is the full arc — what v0.1 proved, what v0.2 honestly lost, what v0.3 fixed, and why the next GPU frontier is joins.

TL;DR — gpudb, the first SQL execution engine for Apple Silicon GPUs, is now an official DuckDB Community Extension. In any DuckDB ≥ 1.5.5: INSTALL gpudb FROM community; — signed, no flags, full Metal backend on M-series Macs. v0.3.0's streaming rewrite reached parity with native DuckDB end-to-end (worst TPC-H cell improved ~100×), while the Metal operator kernels keep their 3–25× wins. Next up: a community-contributed GPU hash join, verified 9.9×.

In May 2026 I shipped something that, as far as I can tell, had never existed: a SQL execution engine that runs on Apple Silicon GPUs. Not a paper, not a prototype in a notebook — a loadable DuckDB extension with real Metal compute pipelines, benchmarked on TPC-H, with a CUDA backend riding the same codebase on Linux. That was gpudb v0.1.0, and the claim was narrow but real: nobody had wired a Mac's GPU into a database before.

Three months and three releases later, two lines crossed at once. The v0.3.0 rewrite reached parity with native DuckDB on end-to-end TPC-H queries — the worst cell improved by roughly 100×. And gpudb became an official DuckDB Community Extension, which means the entire install procedure is now:

INSTALL gpudb FROM community;
LOAD gpudb;

Any DuckDB ≥ 1.5.5, signed binaries, no flags, no downloads. This post is the story of how it got from first kernel to one-line install — including the release where the honest answer was "the SQL path loses by 109×," because that release is the reason the current one works.

Fig 1 — Three months from the first Metal SQL kernel to a signed one-line install. v0.2.0's honest audit is the hinge of the story.

Why an extension, and why Apple Silicon

The GPU-database idea is not new. It is, in fact, a graveyard. MapD became OmniSci became HEAVY.AI and was acqui-hired by NVIDIA in 2025. BlazingSQL went dormant in 2021. Voltron Data cut half its staff in 2025. Sirius — the strongest current academic entry, out of UW with NVIDIA backing at CIDR 2026 — is CUDA-only. Every standalone GPU database asked users to migrate their data and their queries to a new engine, and users kept declining.

Fig 2 — The standalone GPU-database graveyard, 2013–2026. The Apple Silicon lane was empty until May 2026.

gpudb makes two bets against that history. First: be an extension, not a database. DuckDB is already on the machines that matter — analysts' laptops, CI boxes, notebooks — and a loadable extension means zero migration: your files, your SQL, one LOAD. Second: target the hardware nobody else targets. Every engine in that graveyard, and every survivor, is CUDA-only. Meanwhile Apple ships up to 512 GB of unified memory at 819 GB/s on the M3 Ultra — a memory subsystem that would embarrass most server hardware — and no SQL engine had ever touched its GPU.

Fig 3 — Unified memory deletes the PCIe copy tax that killed discrete-GPU databases — and with it, the excuse. On UMA the GPU has to win on compute, not memory locality.

What v0.1 proved: the Apple Silicon GPU is a real analytics device

The first release was about existence proofs, and the numbers were better than I expected. On an M4 Max, against DuckDB's own CPU engine using all 16 threads — the honest baseline, not a strawman single-threaded loop — the Metal operator scorecard came back 9 wins, 1 loss on TPC-H lineitem cells.

Fig 4 — The v0.1.3 Metal scorecard vs DuckDB CPU (16 threads). The 14× loss at 50 unique groups is structural and stays on the card.

The headline is the top of that chart: multi-aggregate fusion. Most real analytical queries don't compute one aggregate — they compute several over the same column (SELECT SUM(x), MIN(x), MAX(x), COUNT(x) is the median TPC-H pattern). Executed naively, that reads the column from DRAM once per aggregate. The fused Metal kernel reads it once and computes all four in a single pass, sustaining about 470 GiB/s on M4 Max — roughly 87% of the machine's memory bandwidth. Fusing four operations into one pass costs zero extra bandwidth, so per-op throughput effectively quadruples. That is where the 22–25× cells come from.

Fig 5 — The fusion wedge: one pass over DRAM instead of three, at ~87% of the M4 Max memory peak.

And the honest loss stays on the card: a GROUP BY with only 50 unique values loses to the CPU by 14×, because the CPU keeps its entire hash table in L1 cache and no GPU dispatch can pay for itself. That's not a bug to fix — it's a boundary to respect, which is why gpudb ships a hybrid planner that routes low-cardinality shapes to the CPU and keeps the GPU for the shapes it wins.

The Linux side: same codebase, opposite physics

The CUDA backend tells the same story from the other direction. On an RTX 4090, a resident-column SUM over 100 million rows sustains 1187 GiB/s — 17.9× over the CPU, finishing in 0.04 ms. But run it cold, and the PCIe transfer costs 80 ms before the 0.04 ms kernel even starts.

Fig 6 — The CUDA lane on RTX 4090: 1187 GiB/s resident, PCIe-bound cold. Discrete GPUs push the design toward resident columns; unified memory pushes it toward compute-dense operators.

On a discrete GPU the transfer is the enemy, so the design wants resident columns. On unified memory the transfer is free — but so is the CPU's access to the same bytes, so the design wants compute-dense operators. One codebase, two backends, and the two lessons turn out to be mirror images of each other. Which brings us to the release where I had to learn that the hard way.

v0.2: the release that lost, on the record

The operator scorecard above is measured at operator level — the kernels against the CPU doing the same work. v0.2.0 asked the harsher question: what happens end-to-end, through the DuckDB CLI, on real rewritten TPC-H queries, extension versus native? The answer, recorded in BENCHMARK.md with a straight face: the extension lost every cell, by 3× to 109×.

The cause wasn't the GPU — it was the plumbing around it. The v0.2 aggregate path buffered every incoming value into per-state vectors and reduced at finalize. On unified memory, that copy is the whole cost: the query spends its time duplicating a column DuckDB already holds in memory, then a fast reduction at the end saves nothing. The 4-point analysis in the benchmark log predicted the loss was structural, not tunable. It was right.

v0.3: parity, by deleting work instead of adding it

The v0.3.0 rewrite replaced the buffered path with streaming running accumulators — the same algorithmic shape as a native DuckDB aggregate. No buffering, no copy, no finalize-time reduction. And on unified memory, one more consequence falls out: for a plain scalar aggregate over a column, the rewritten path doesn't dispatch to the GPU at all, because shipping bytes to a coprocessor that shares your memory just to add them up is pure overhead.

Fig 7 — v0.2.0's 3×–109× end-to-end losses collapse to 1.00×–1.20× in v0.3.0, with identical results. The SF10 GROUP BY cell alone improved ~100×.

Every cell is now within 0–20% of native — Q6 at SF1 is a dead-even 1.00×, and the worst cell (SF1 GROUP BY) is 1.20×. The SF10 GROUP BY went from 11.05 seconds to 0.109 seconds. Correctness was gated before any timing counted: Q6 revenue totals match native to the printed digit, Q1 row sets match row-for-row, GROUP BY checksums are identical at both scale factors. The remaining 0–20% is recorded as unprofiled, because it is.

I want to be precise about what this means, because it's the most honest sentence in the release: v0.3's parity came from teaching the extension when not to use the GPU. The GPU's wins remain at operator level — the fused multi-aggregates, the large GROUP BYs, the shapes in Fig 4 — and the hybrid planner routes to them. What v0.3 fixed is that using gpu_* aggregates in an ordinary query is no longer a footgun. The extension now costs nothing where the GPU can't help, and pays off where it can.

Fig 8 — The v0.3 lesson: scalar bandwidth-bound work goes to the CPU, compute-dense operator work goes to the GPU — and joins are the next compute-dense frontier.

Distribution: the part indie projects usually never solve

A database extension you have to compile from source, or load with security flags disabled, is a demo. The DuckDB Community Extensions registry is what turns it into software: the DuckDB team's infrastructure builds the extension from source on every platform, signs the binaries, and serves them to every DuckDB client. Two merged PRs later (#1898 for acceptance, #2404 for the version bump), the registry now ships gpudb v0.3.0 on all four platforms — with the full Metal backend in the Apple Silicon build, and a clean CPU fallback elsewhere. If you have DuckDB 1.5.5 or newer on an M-series Mac, you are one SQL statement away from Metal kernels. (The CUDA backend still needs a source build on Linux — toolchain packaging is a v0.4 item.)

Fig 9 — Two merged community-extensions PRs later, the registry builds, signs and serves v0.3.0. Apple Silicon gets the full Metal backend.

What's next: joins, and a contributor I didn't recruit

The best signal a small open-source project can get is a stranger showing up with working code. gpudb's PR #43 is exactly that — a real Metal hash join with an on-device segment reduce and a gpu_inner_join surface, contributed from outside, verified at 9.9× on a 1M × 10M inner join on M4 Max. It's landing after a rebase pass, and it defines the v0.4 arc: joins are compute-dense in precisely the way scalar aggregates aren't, which makes them the right SQL-path GPU story on unified memory. The roadmap after that — resident-column SQL hooks, GPU window operators, and string operators on Metal where nothing like libcudf exists — is in the repo.

Try it

If you have an Apple Silicon Mac and DuckDB ≥ 1.5.5, the whole experiment is thirty seconds:

INSTALL gpudb FROM community;
LOAD gpudb;
SELECT gpu_sum(value::BIGINT) FROM range(1000000) AS t(value);
-- 499999500000, via a Metal streaming aggregate

The repo is github.com/singhpratech/duckdbgpumetaldbram — Apache-2.0, with every number in this post reproducible from BENCHMARK.md, losses included — and the extension's official home is its DuckDB Community Extensions page. The full technical write-up — architecture, kernel design, and the complete benchmark tables with an August 2026 addendum — is in the gpudb paper on this site. Thirteen years of GPU-database history says the standalone play doesn't survive. The bet here is different: ride an engine people already trust, target the hardware nobody else does, and report the 14× losses next to the 25× wins. So far, that bet is one merged registry and one external contributor ahead.
